Summary

Feature:

Rough Terrain Crane

Condition:

New

Application:

Construction

Brand Name:

ZOOMLION

Model Number:

RT100

Certification:

ISO,CE

Rated Loading Capacity:

100t

Rated Lifting Moment:

3339kN.M

Dimension:

14247×3620×3960mm

Max. Lifting Load:

100t

Max. Lifting Height:

45.6m

Place of Origin:

Jiangsu, China (Mainland)

Warranty:

1 year

Span:

8.0/7.9m

After-sales Service Provided:

Engineers available tc

Specifications

Packaging & Shipping

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

10 days

Details

Category	Item				Unit	Parameter
Dimensions	Dimensions (Length×width×height)				mm	16225×3000×3995
	Wheel base				mm	2650+1650+2900+1650
	Track (Front/ Rear)				mm	2590
	Front/ Rear overhang				mm	2660/2135
	Front/ Rear extension				mm	2325/255
Weight	Max. permissible weight				kg	54990
	Axle load	1st axle			kg	11490
		2nd axle			kg	12000
		3rd axle			kg	12000
		4th axle			kg	9900
		5th axle			kg	9600
	Rated power/rpm				kW/(r/min)	390/1900
	Max. net power/rpm				kW/(r/min)	385/1900
	Max. torque/rpm				N.m/(r/min)	2500/1000-1400
Travel	Max. travel speed				km/h	≥80
	Min. travel speed				km/h	≤5
	Min. turning diameter				m	≤18.5
	Min. turning diameter at boom tip				m	≤23
	Min. ground clearance				mm	307
	Approach angle				°	19
	Departure angle				°	16
	Braking distance (at 30 km/h )				m	≤10
	Max. grade ability				%	≥60
	Fuel consumption per 100 km				L	70
Noise	Exterior noise level				dB(A)	≤88
	Noise level at seated position				dB(A)	≤90
Main performance	Max. total rated lifting capacity				t	160*
	Min. rated working radius				m	2.5
	Turning radius at turntable tail		Counterweight		mm	5110
			Auxiliary winch		mm	4960
	Max. load moment		Base boom		kN.m	5145
			Fully-extended boom		kN.m	2115
			Fully-extended boom + Jib		kN.m	1940
	Outrigger span		Longitudinal		m	8.99
			Lateral		m	7.9
	Hoist height		Base boom		m	14.9
			Fully-extended boom		m	76.9
			Fully-extended boom + Jib		m	103.1
	Boom length		Base boom		m	14.4
			Fully-extended boom		m	78
			Fully-extended boom + Jib		m	107.4
	Jib offset angle				°	0、15、30
Working speed	Boom raising time				s	≤60
	Boom fully extended time				s	≤760
	Max. slewing speed				r/min	≥1.5
	Outrigger extending and retracting time		Outrigger beam	Retracting	s	≤40
				Extending	s	≤40
			Outrigger jack	Retracting	s	≤60
				Extending	s	≤90
	Hoisting speed (single line, 4th layer, no load)		Main winch		m/min	≥135
			Auxiliary winch		m/min	≥90
Noise	Exterior noise level				dB（A）	≤110
	Noise level at seated position				dB（A）	≤85

Packing & Shipping

40'HQ Container

RoRo Shipment

flat rack container

bulk shipment

road transportation

railway transportation

After-Sales Service

Warranty

SKYMARD grants our clients a twelve-month-period (1 Year) or 2000-hours warranty for any machine purchased from us. During the warranty period, in case the defect of material or workmanship has occurred with spare parts in normal operation, the defective part will be repaired or replaced free of charge as compesaion, at our discretion.

Spare Parts

SKYMARD is dedicated to provide our clients with genuine spare parts with the highest quality, exact fitness and appropriate function. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are. Please submit your spare parts request to us, and list product name, model, equipment serial number, description of required parts. We guarantee that your request will be handled quickly and appropriately.

Installation

SKYMARD is able to provide you with the overall installation of complicated machinery and equipment, allowing you to start the proper operation of construction machine. After installation, we will make inspection of the whole machine, operate equipment, and provide you with testing data reports of installation and operation. We can also send engineers to client's site to do maintenance work.

Training

SKYMARD offers perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know how training, standards, laws and regulations training and other trainings, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.
